apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: elasticsearch-logging
  namespace: logging
  labels:
    k8s-app: elasticsearch-logging
    version: v7.10.2
    addonmanager.kubernetes.io/mode: Reconcile
spec:
  serviceName: elasticsearch-logging
  replicas: 2
  selector:
    matchLabels:
      k8s-app: elasticsearch-logging
      version: v7.10.2
  template:
    metadata:
      labels:
        k8s-app: elasticsearch-logging
        version: v7.10.2
    spec:
      serviceAccountName: elasticsearch-logging
      containers:
        - image: quay.io/fluentd_elasticsearch/elasticsearch:v7.10.2
          name: elasticsearch-logging
          imagePullPolicy: Always
          ...
          ports:
            - containerPort: 9200
              name: db
              protocol: TCP
            - containerPort: 9300
              name: transport
              protocol: TCP
          volumeMounts:
            - name: elasticsearch-logging
              mountPath: /data
          env:
            - name: "NAMESPACE"
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            - name: "MINIMUM_MASTER_NODES"
              value: "1"
      volumes:
        - name: elasticsearch-logging
          emptyDir: {}  ### 生产上不要挂在本地
      # Elasticsearch requires vm.max_map_count to be at least 262144.
      # If your OS already sets up this number to a higher value, feel free
      # to remove this init container.
      initContainers:
        - image: alpine:3.6
          command: ["/sbin/sysctl", "-w", "vm.max_map_count=262144"]
          name: elasticsearch-logging-init
          securityContext:
            privileged: true

  <source>
      @id fluentd-containers.log
      @type tail
      path /var/log/containers/*.log  ### 宿主机映射到容器的目录
      pos_file /var/log/es-containers.log.pos ### position日志,消费偏移量
      tag raw.kubernetes.*
      read_from_head true
      <parse>
        @type multi_format
        <pattern>
          format json
          time_key time
          time_format %Y-%m-%dT%H:%M:%S.%NZ
        </pattern>
        <pattern>
          format /^(?<time>.+) (?<stream>stdout|stderr) [^ ]* (?<log>.*)$/
          time_format %Y-%m-%dT%H:%M:%S.%N%:z
        </pattern>
      </parse>
    </source>

  output.conf: |-
    <match **>
      @id elasticsearch
      @type elasticsearch
      @log_level info
      type_name _doc
      include_tag_key true
      host elasticsearch-logging ### service的名字[集群内部的]
      port 9200
      logstash_format true
      <buffer>
        @type file
        path /var/log/fluentd-buffers/kubernetes.system.buffer
        flush_mode interval
        retry_type exponential_backoff
        flush_thread_count 2
        flush_interval 5s
        retry_forever
        retry_max_interval 30
        chunk_limit_size 2M
        total_limit_size 500M
        overflow_action block
      </buffer>
    </match>

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: fluentd-es-v3.1.1
  namespace: logging
  labels:
    k8s-app: fluentd-es
    version: v3.1.1
    addonmanager.kubernetes.io/mode: Reconcile
spec:
  selector:
    matchLabels:
      k8s-app: fluentd-es
      version: v3.1.1
  template:
    metadata:
      labels:
        k8s-app: fluentd-es
        version: v3.1.1
    spec:
      securityContext:
        seccompProfile:
          type: RuntimeDefault
      priorityClassName: system-node-critical
      serviceAccountName: fluentd-es
      containers:
      - name: fluentd-es
        image: quay.io/fluentd_elasticsearch/fluentd:v3.1.0
        env:
        - name: FLUENTD_ARGS
          value: --no-supervisor -q
        ...
        volumeMounts:
        - name: varlog
          mountPath: /var/log
        - name: varlibdockercontainers
          mountPath: /var/lib/docker/containers ### 收集打到控制台的日志
          readOnly: true
        - name: config-volume
          mountPath: /etc/fluent/config.d
        ports:
        - containerPort: 24231
          name: prometheus
          protocol: TCP
          ...
      terminationGracePeriodSeconds: 30
      volumes:
      - name: varlog
        hostPath:
          path: /var/log
      - name: varlibdockercontainers
        hostPath:
          path: /var/lib/docker/containers
      - name: config-volume
        configMap:
          name: fluentd-es-config-v0.2.1
